Question

Given a binary tree

struct TreeLinkNode {
  TreeLinkNode *left;
  TreeLinkNode *right;
  TreeLinkNode *next;
}

Populate each next pointer to point to its next right node. If there is no next right node, the next pointer should be set to NULL.

Initially, all next pointers are set to NULL.

Note:

• You may only use constant extra space.
• Recursive approach is fine, implicit stack space does not count as extra space for this problem.
• You may assume that it is a perfect binary tree (ie, all leaves are at the same level, and every parent has two children).

Difficulty:Medium

Category:Tree, Depth-First-Search

Analyze

方案一：递归 (Solution 1)

这道题目是完全二叉树，所以如果节点的左子节点存在的话，那么右子节点必定存在：

• 如果左子节点存在，那么左节点的next指针可以直接指向其右子节点
• 对应右节点，判断其父节点的next是否为空，如果不为空，那么就指向父节点next指针指向的节点的左子节点，如果为空那么就指向NULL.

方案二：迭代 (Solution 2)

Solution

Solution 1:递归的解决方案

/**
 * Definition for binary tree with next pointer.
 * struct TreeLinkNode {
 *  int val;
 *  TreeLinkNode *left, *right, *next;
 *  TreeLinkNode(int x) : val(x), left(NULL), right(NULL), next(NULL) {}
 * };
 */
class Solution {
 public:
  void connect(TreeLinkNode *root) {
    if (root == nullptr) return;
    if (root->left) root->left->next = root->right;
    if (root->right) root->right->next = root->next ? root->next->left : NULL;
    connect(root->left);
    connect(root->right);
  }
};

Solution 2: 迭代的解决方案

class Solution {
 public:
  void connect(TreeLinkNode *root) {
    while (root) {
      TreeLinkNode *next = nullptr, *prev = nullptr;
      // Loop in the same level
      for (; root; root = root->next) {
        // The first one --> to find the next level
        if (!next) next = root->left ? root->left : root->right;

        if (root->left) {
          if (prev) prev->next = root->left;
          prev = root->left;
        }

        if (root->right) {
          if (prev) prev->next = root->right;
          prev = root->right;
        }
      }
      root = next;  // Next Level
    }
  }
};
